EMC-008Motorcycle
Honda CD70 clutch drive plate in SG iron
Honda CD70 motorcycle
A compact clutch component for Pakistan's most common motorcycle, produced in batches.
- Material
- SG (ductile) iron
- Process
- Sand casting
- Machining
- Faces turned, splined bore, bosses drilled and tapped
- Supply
- Batch production
About this part
It has a splined centre bore, eight drive tabs on the rim, four raised pegs and four threaded bosses, all on a part that fits in your hand. Small parts are unforgiving: the castings have to come out consistent and the threads clean, or the plate will not drop into the clutch pack. Volume work like this is where a repeatable mould earns its keep.
How we make it
- Sand cast in SG (ductile) iron
- Faces turned
- Splined centre bore machined
- Four bosses drilled and tapped, outer tabs finished
- Dimensional, thread and visual checks
Do you make other motorcycle clutch parts?
We work from your sample or drawing, so other clutch and drivetrain components are possible. Send the part you need.
What quantities do you run?
Small parts like this are made in batches. Tell us your monthly requirement and we will quote against it.
